Portable Video Laryngoscope Flexible Fiberoptic Diagnostic Mac 4 Blade Intubation

Product Categories
Besdata  Technology Company Limited
Contact Now

Portable Video Laryngoscope Flexible Fiberoptic Diagnostic Mac 4 Blade Intubation

Brand Name : BESDATA

Model Number : BD-AD

Certification : CE / ISO13485

Place of Origin : CE / ISO13485

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 set per month

Delivery Time : 2~7 days

Packaging Details : in a customized box

Weight : 180g

Resolution : 480*640

Anti-fog : yes

Depth of field : 3-60mm

Disinfection : IPX7

Color : blue and white

Contact Now

Portable Video Laryngoscopy FlexibleFiberoptic Diagnostic Mac 4 Blade Intubation


Main Features:

  1. 2.5'' display
  2. Camera Resolution: 0.3 Mpixel
  3. Reusable blade: Adult, Children, Neonate
  4. Compatible with disposable blade
  5. Video synchronous transmission to big monitor by AV cable
  6. Easy to input the tracheal tube by good view of glottis,Smart Anti-Fog
  7. Built-in rechargeable battery.1150mAh lithium battery,can be used nearly 4 hours after 1 time charge.
  8. Easy to Disinfect
  9. More curved blade angle makes it can cope with most difficult airway management
  10. cost-optimal in the market




Specifications:

NameTechnical namesTechnical indicators
Machine parametersDisplay2.5"(LCD)
Camera Resolution640X480, 0.3Mpixels
Rotating angles of the monitor in front and rear0 º~130 º
Rotating angles of the monitor in right and left0 º~270 º
Angle of vision≥60º
Power consumption<2W
Discharging time of battery>1h
Charging times>300times
Weight180g
ChargerCharger input~220V50Hz
Charger output4.2V, 500mA
Charging time<4(hrs)
Working environmentsTemperature10℃~40℃
Humidity10%-90%
Atmospheric pressure500hpa-1060hpa
Transportation storage environmentsTemperature-40℃~55℃
Humidity≤93%
Atmospheric pressure500hpa~1060hpa



Blade different from the traditional type.

Special blade design more confortable for patient, more suitable for all size endotracheal tube.

The more angle and wide view field makes it can cope with more difficult airway.




Our Services
After Sales Service Process(Two years warranty)

1 Confirm Receiving
2 Trouble Shooting
3 Fill in the Abnormal Information List
4 Meet the requirement of sending back
5 Sending back the Product
